XR130E
A versatile heavy-duty machine designed for construction tasks. Offers powerful performance with stable operation. Built with advanced engineering for durability. Easy to operate with safety-focused features. Ideal for demanding work environments.
Quick highlights
Displacement
1200cc
Transmission
Manual
Fuel Type
Gasoline
Hassle Free Delivery
Peace of mind
Best Buying Experience
We share happiness
After-Sale Service
Best Service Offered
Detailed Specifications
| Certification | CE/ISO9001 |
| Dimension (LWH) | -- |
| Weight | 45t |
| Power (W) | -- |
| Voltage | -- |
| Usage | Ore |
| Model Number | XR130E |
| Brand Name | XCMG |
| Place of Origin | China |
| Power Type | Diesel |
| Type | Rotary Drilling Rig |
| Engineering & Construction Machinery | XR130E |
Parameter | Unit | XR130E |
|---|---|---|
| Engine Model | — | QSB7-C227 |
| Rated Power | kW | 169 |
| Rotary Drive Max. output torque | kN·m | 130 |
| Rotary Speed | r/min | 8~35 |
| Max. Drilling Diameter | mm | 2500 |
| Max. Drilling Depth | m | 50 |
| Main Winch Max. Pulling Force | kN | 140 |
| Main Winch Max. Line Speed | m/min | 75 |
| Auxiliary Winch Max. Pulling Force | kN | 50 |
| Auxiliary Winch Max. Line Speed | m/min | 70 |
| Mast Rake (Side/forwards/backwards) | ° | 3 |
| Undercarriage Max. Traveling Speed | km/h | 2.7 |
| Undercarriage Max. Grade Ability | % | 40 |
| Undercarriage Min. Clearance | mm | 345 |
| Track Shoe Width | mm | 600 |
| Distance Between Tracks | mm | 2500~3600 |
| Hydraulic System Working Pressure | Mpa | 35 |
| Overall Drilling Weight | t | 45 |
| Dimension (Working Condition) | mm | 7546×3600×17724 |
| Dimension (Transportation Condition) | mm | 14097×2500×3500 |
| Certification | CE/ISO9001 |
| Weight | 45 |
| Usage | Ore |
| Model Number | XR130E |
| Brand Name | XCMG |
| Place of Origin | China |
| Power Type | Diesel |
| Type | Rotary Drilling Rig |
| Weight | 45000 |
| Condition | New |
| Moving Type | Other |
